  1. Got the ports all cleaned, fresh gaskets, fresh hardware and the headers bolted up. Now just have to sort through the O2 sensor wiring because I’m an idiot and didn’t mark them. I'll have to fire up Ecuworx too and code out the downstream O2 sensor and secondary air pump so we don't get a CEL.
  2. Replaced the CPV o-ring with a viton one while I was waiting on parts to finish the headers. It wasn’t leaking, but seems like a PITA to replace later. While in there I noticed the cam position sensor is leaking a bit. Death by 1000 gaskets…
  3. Waiting on some suspension parts yet so I started the header install. Have to say that this is MUCH harder than the downpipe install on my F30. Since there's such limited room to work I had to remove the coolant reservoir tank, turkey basting out all the coolant so I didn't make an absolute disaster. Still probably spilled 1/2 gallon on the floor that came out the other end though lol. Even with this and the heat shielding out of the way, access to the 18 nuts is still pretty grueling. Just kept swapping out swivel, wobble and regular extensions, as it seems like each nut requires a different approach. After a few hours I finally got the old set out, woohoo! Still waiting on new gaskets and nuts, but should be here in about a week or so and I can get the new headers installed.
  4. Honestly fairly new to the intricacies of suspension tuning so I reached out to TC Kline and got this response I could see how adjustable links could come into play with corner balancing, but I've also read BMWs are pretty well balanced from the factory. I'll definitely do my best to test out all this info and report back though!
  5. Got the new shocks from TCK already! Time to swap the GC camber plates on and get these installed. Still not sure if the factory end links will fit. If not, maybe that'll be an excuse to replace them and upgrade front sway bars too.
  6. Yeah they are custom valved to the springs. I did give the spring rates to TCK when ordering, so hopefully the replacements are an exact match. Honestly not sure how to confirm or deny that though
  7. I ended up buying some TC Kline coilovers from a forum member on nam3forum. They were advertised as a 3000 mile set and they looked pretty solid in the sellers photos. Upon getting them I realized he might have forgotten a 0 or two on the mileage. The two fronts are blown and the rears have a pretty old build date. This set is nearly $3200 new, so I hoped I could save a few bucks buying used. NOPE no chance. Bought two new front replacements that are on their way from TCK. Going to rock the rears until they wear out, might have another season or two in them. On the bright side, I did get Ground Control camber plates included. They were a bit dirty and beat up, so I did my best to clean and re-grease the bearings. Think they'll work just fine.
  8. I can’t believe those fit in the backseat of the M3 lol. Those are going to be such a sweet upgrade going into winter, nice find!
  9. Tiny change, but swapped out the indicator bulbs with chrome coated ones. Barely noticeable but I think it’s subtly better looking in the clear housing. Good tip @Rekpoint
  10. Looks great! Is that the M Performance kit? I feel like I've seen those side skirts before and they look much different than the M Sport on my E90!
  11. New fear unlocked right before I do my suspension overhaul. Did the bolt head snap off while hitting it with an impact? That really sucks, but hopefully the shock isn't threaded so it could just slip off and you only have to buy one new thing
  12. Finally got my new Rogue Engineering Delrin oval carrier bushings and continued on with the install. I would say the rest of the job was like fighting a grizzly bear on meth. My hands are raw, there is zero room to work, most of the job is by feel with no line of sight and there was no part of this job that didn't fight me until I just about gave up. Here's a list of things that went wrong: Ordered the wrong carrier bushings, circle rather than the correct oval ones I installed the carrier upside down while not paying attention, and sadly I snapped the "bitch clip" down, the one notoriously nicknamed for being nearly impossible to remove Bimmerworld sent me a "bitch clip" thats backwards, causing the part you need to pry against to be inaccessible The UUC selector rod wouldn't fit on the shift rod joint, the built in bushings were preventing it from sliding on by about 1-2mm. I had to remove the carrier a 3rd time, because it needs to be off to take the shift rod joint out, so I could modify it to fit the DSSR Lots of swearing and some perseverance I got it done. I ended up removing the selector rod joint and actually sanding down the plastic bushings so they are nearly flush. I'm not sure if this will have consequences down the road, but it articulates freely and I added some grease. Worst case I'm pretty well versed in removing it by now. I can't actually test it out since it's winter and the salt trucks have already been out here in Minneapolis, but I did row through the gears in the garage and it feels AWESOME. Virtually zero slop and feels like bolting a rifle or rowing a gated manual. I'm sure most would consider this a relatively easy job, but man this kicked my ass. Proud to have done it myself though, since my local shop quoted me at $550 for labor. Edit: If you notice the random paint on the rear of the carrier, that's because I scratched the hell out of the sheet metal trying to remove that rear carrier bushing. Added some automotive paint I had laying around to prevent corrosion with the exposed metal. Whoopsie.
  13. Decided to give the UUC EVO 3 SSK + DSSR kit a go today. Kind of a pain to get to everything. Needed to drop the section 1 exhaust to access the trans brace, tilt the transmission down a couple inches just to reach the top clip on the shift carrier. Figured I might as well swap out the trans mounts with some new UUC ones too while I was at it. Managed to get everything removed (aside from the rear shift carrier bushing, that thing was FUSED to the car. If anyone says they removed it they're lying). Once I had all the shifter components out though, I realized I ordered the wrong front carrier bushing and need the oval one. Damn it, to be continued...
  14. Just remembered I also had the oil pump nut tack welded on. Was reading it was rare, but possible for the nut to back off and then boom. I know I should have used a safety wire nut, but since this component will never need to be removed (if I upgrade, I’ll get the VAC kit with sprocket included), I didn’t care as long as it was a permanent fix.
  15. Finally sucked it up and committed to getting the rod bearings done. This car had them done as part of the recall way back in ‘06 at 66k miles (car is at 135k now), but black stone tests had me a bit nervous. Once they were pulled they honestly didn’t seem that bad. Seems like cylinder 6 was the main culprit to the test results. Went with WPC treated OE bearings and ARP bolts. Also replaced the oil pan gasket, oil pump seals, motor mounts and a leaking power steering line while it was apart.
